Feedstock Pre-Treatment EquipmentIndustrial Napier Grass Shredder
Specifically engineered for heavy-duty size reduction of green fodder and biomass crops. Optimizes digestion efficiency for Indian Bio-CBG and silage projects.
High-Capacity Biomass Processing Solution
Our Napier Grass Shredder / Chopper is a heavy-duty, high-performance machine specially designed for efficient cutting, shredding, and size reduction of green fodder and biomass materials. It is widely used in cattle feed plants, silage preparation units, BIO-CBG plants, biogas facilities, composting units, and biomass processing industries.
The machine is engineered for continuous operation with low maintenance and high output efficiency, making it ideal for both agricultural and industrial applications.
Key Features
Heavy-duty MS fabricated body
Build for extreme mechanical loads and steady industrial operation.
Hardened Blades & Hammers
High-speed rotor equipped with durable alloy steel cutters.
Wet & Dry Biomass Handling
Optimized feeding geometries to process raw crops of varying moistures.
Continuous Operation
Built with high torque to withstand uninterrupted continuous feeding.
Adjustable Output Sizes
Easily modify sizing outputs to fine-tune retention rates.
Low Power Consumption
High efficiency motors minimize operational power costs (kWh/Ton).
Multi-Drive Compatibility
Available in Electric, Diesel & PTO tractor operated models.
Water-Assisted Grinding
Optional integration for pre-wetting feedstock for quick digestion.
Suitable Input Materials
Designed to shred highly tough, stringy, and fibrous agricultural residues:
Napier Grass
Hybrid high-energy crops
Maize Stalk
Moist corn residues and stalks
Sugarcane Trash
Fibrous cane trash and leaves
Paddy Straw
High-silica tough rice straw
Sorghum Stalk
High-juice sweet sorghum crop residues
Organic Green Waste
Horticulture residues and municipal waste
Wet Biomass for BIO-CBG Plants
Pre-conditioner for anaerobic digestion
BIO-CBG Feed Preparation Process
An optimized feed sizing pipeline ensures uniform slurry preparation and prevents crust formation inside digesters.
Biomass Collection
Sourcing Napier/Straw feedstock
Feeding Conveyor
Uniform continuous feeding
Shredder / Grinder
Size reduction under 15mm
Water Mixing
Optional pre-wetting dilution
Slurry Tank
Homogenized mixing
Pumping to Digester
Anaerobic feeding stage
Product Models & Capacity Specifications
Standard B2B capacity segments customized to suit agricultural clusters, silage operations, and Bio-CNG plants.
| Model | Capacity (TPH) | Power Required | Blade / Hammer Configuration | Action |
|---|---|---|---|---|
| NS-3 | 1 - 3 TPH | 7.5 - 10 HP (Electric / Tractor PTO) | 12 / 24 Cutter Hammers | |
| NS-5 | 3 - 5 TPH | 10 - 15 HP (Electric / Tractor PTO) | 16 / 32 Cutter Hammers | |
| NS-10 | 7 - 10 TPH | 20 - 30 HP (Electric / Tractor PTO) | 24 / 48 Cutter Hammers | |
| NS-15 | 10 - 15 TPH | 40 - 60 HP (Electric / Engine) | 32 / 64 Cutter Hammers |
Drive Adaptability Options
We offer multiple drive choices to suit your installation environment and resource access.
Electric Motor Operated
Energy efficient and ideal for fixed installations with steady grid connection. Minimizes ongoing operational footprint.
Applications
Agriculture & Dairy
- Green fodder preparation
- Silage making
- Cattle feed processing
BIO-CBG / Biogas Plants
- Biomass feedstock preparation
- Slurry preparation for digesters
- Organic waste processing
Biomass Industries
- Composting units & Ethanol plants
- Biomass pellet plants
- Organic fertilizer manufacturing
